Warrior 1400X

The Powerscreen® Warrior 1400X is a flexible screening machine, aimed at operators who require a high performing, heavy duty, versatile machine that remains easy to transport. It offers improved performance, lower operating costs, and easier serviceability while building on the reliable foundation of our class-leading Warrior 1400 scalper. Its highly aggressive screen can accept bofor bars, finger screens, woven mesh and punch plates.

User benefits include jack up screen facilities to aid media access and hydraulic screen angle adjustment.

Description

The Powerscreen® Warrior 1400X is a flexible screening machine, aimed at operators who require a high performing, heavy duty, versatile machine that remains easy to transport. It offers improved performance, lower operating costs, and easier serviceability while building on the reliable foundation of our class-leading Warrior 1400 scalper. Its highly aggressive screen can accept bofor bars, finger screens, woven mesh and punch plates.

User benefits include jack up screen facilities to aid media access and hydraulic screen angle adjustment.

Specifications

2 Way Split 3 Way Split
Weight 25,000kg (55,115lbs) 27,500kgs (60,627lbs)
Transport width 2.75m (9′) 2.75m (9′)
Transport length 13.62m (44’8″) 14.21m (46’7″)
Transport height 3.2m (10’6″) 3.2m (10’6″)
Working width 8.13m (26’8″) 12.59m (41’3″)
Working length 13.96m (45’10”) 14.20m (46’7″)
Working height 4.40m (14’5″) 4.57m (15′) hopper extended
Working height 4.87m (16′) hopper extended, with chassis riser
Screenunit 3.6m x 1.25m (12′ x 4.5′) 3.6m x 1.25m (12′ x 4.5′)
* All information subject to machine configurations & specifications ordered.
** Lincom reserves the right to change specifications without prior notice.

Features & Benefits

  • Output potential up to 500 tph (551 US tph)
  • Heavy duty, incline belt feeder with rigid one piece hopper
  • Heavy duty, adjustable angle, grease lubricated 2 bearing, 2 deck screen box
  • Jack up screen facility to aid mesh changes
  • Screen walkway & access steps
  • Hydraulic folding conveyors with excellent stockpiling capacity
  • Engine protection shutdown system
  • Rapid set-up & shutdown time
  • Two speed tracks
  • Collection conveyor raise feature
  • Reversible side conveyors

Options

  • Radio controlled tracking
  • Dual power (additional electric hydraulic drive)
  • Quick release screen wedge tensioning
  • Auto lubrication system
  • Dust suppression
  • Wide range of screen media
  • 2 or 3 way split configuration
  • High capacity incline apron feeder
  • 300mm (12″) Chassis riser
  • Telescopic side conveyors
  • Hopper extensions
  • Screen blanket
