Designed to deliver exceptional productivity, fuel efficiency, and versatility, these impact crushers are ideal for contractors, quarry operators, recyclers, and mining applications.
Built around a powerful horizontal shaft impactor (HSI), the Trakpactor 480 range combines aggressive crushing performance with advanced design features that maximise throughput while reducing operating costs.
At the heart of the Trakpactor 480 and 480SR is a highly aggressive impact crushing chamber featuring a 1270mm x 870mm (50″ x 34″) feed opening, a 4-bar rotor, and a 2-apron crushing system. This proven design delivers excellent reduction ratios, consistent product sizing, and high production capacity across a variety of applications.
Features & benefits:
- High-capacity impact crusher featuring a 1270mm x 870mm (50″ x 34″) feed opening, delivering excellent reduction ratios and consistent product sizing across a wide range of materials.
- Aggressive 4-bar rotor and 2-apron crushing chamber designed to maximise productivity and achieve high-quality end products.
- Fuel-efficient direct drive system via a Desch gearbox, helping to reduce fuel consumption and lower operating costs.
- Integrated post-screening and recirculation system on the Trakpactor 480SR, allowing oversized material to be returned to the crusher for further processing and improved product quality.
- Quick attach/detach SR section enables the Trakpactor 480SR to convert to a standard Trakpactor 480 in minutes, providing greater operational flexibility.
- Excellent service access with a ground-level hydraulic cabinet, unrestricted access to both sides of the power unit, and durable steel pipework in key locations to simplify maintenance and maximise uptime.
